200W 3C+3A Port GaN USB-C Charger

One compact brick to power your retro shelf. Six ports and 200 W of total output let you run several USB-C console adapters from a single wall socket, instead of cluttering a power board with individual bricks.

Console Compatibility

Every console power product we stock needs one of three USB-C PD profiles. Here is where this charger supplies each one:

• 9 V — the 9 V cable and adapter versions: PD1, PD2 and PD3.
• 12 V / 3 A — the GameCube and Wii versions, the Saturn, Dreamcast, PlayStation 1 and GameCube boards, and the N64 Pow: PD1 only (PD2 and PD3 top out at 12 V / 2.5 A).
• 15 V / 3 A — the Wii U version and the PlayStation 2 board: PD1 only (PD2 and PD3 top out at 15 V / 2 A).
• USB-A ports — QC1 to QC3 are Quick Charge ports for accessories and lighting, not for USB-C PD console adapters.

Tip: reserve PD1 for your 12 V and 15 V adapters, as it is the only port that supplies them at a full 3 A. PD2 and PD3 are ideal for the 9 V leads for the NES, SNES, Mega Drive and PC Engine.

Key Features

• 200 W total output across six ports
• Six ports — three USB-C PD plus three USB-A Quick Charge
• 12 V / 3 A and 15 V / 3 A on PD1
• Up to 100 W from PD1
• GaN semiconductor technology — higher efficiency, less heat and a smaller body than a conventional charger of the same output
• Australian plug
• CE and UL certified, with protection against over-current, overheating and short circuits

Output Specifications

• PD1: 5V/3A · 9V/3A · 12V/3A · 15V/3A · 20V/5A — 100 W max
• PD2 / PD3: 5V/3A · 9V/3A · 12V/2.5A · 15V/2A · 20V/1.5A — 30 W max
• QC1 / QC2 / QC3: 5V/3A · 9V/2A · 12V/1.5A — 18 W max
• Shared output: PD1 + PD2 together deliver 45 W + 30 W; PD3 alongside the QC ports delivers 5 V / 3 A
• Total output: up to 200 W

Why GaN?

Gallium nitride switches far more efficiently than the silicon used in older chargers, so it wastes less energy as heat. That efficiency is what makes this much output possible from a compact unit — and it keeps the charger cool while it works.

Good to Know

The headline 200 W is the peak capability; with several ports in use the combined output is shared between them. Every console power adapter has its own voltage and current requirement — check that yours is met by the port you plug it into. Not sure what a port can deliver? Our USB-C PD power meter reads the real figures back. Sold as a single charger; USB-C cables are not included.
